RECORDING WEEK 2023: Led Zeppelin IV - actually, the album is officially untitled - was released on 8 November 1971, and has so far racked up over 37 million sales. Here, to celebrate the anniversary of its release, read on to learn how the album's distinctive sonic signature was created.
Classic Interview: Andy Johns, the younger brother of another famed engineer, Glyn Johns, began his career working as an assistant engineer with Eddie Kramer on Jimi Hendrix sessions.
Andy also engineered The Rolling Stones' Exile on Main Street and worked with Free, Blind Faith and Van Halen.
Andy was instrumental in shaping the sound of Led Zeppelin's seminal fourth album, including John's Bonham's ferocious drum sound on When The Levee Breaks.
Sadly, Johns passed away in 2013, but in this 2009 interview he recalled the highs and lows of those sessions...
Where did you kick off the sessions for Led Zep IV?
"The Rolling Stones had the first mobile recording unit in Europe. I had done the Stones' album Sticky Fingers and I had also done two other album projects at Mick's house, Stargroves, with the truck and I really liked it. It was a lot of fun and you got so many different spaces and it was better than being stuck in some airless, windowless room.
"We were getting ready to do the next Led Zeppelin album and I said to Jimmy Page: 'Why don't we use the Stones' truck and we'll go to Mick's house?' So Jimmy says: 'How much will that cost?' It worked out to be the same as a regular studio and a thousand pounds a week for Mick's house.
"He said: 'I'm not giving Mick Jagger a thousand pounds a week for his place. I'm going to find something better than that.' And he found Headley Grange, which was rather fortunate. We did a few tracks there including When The Levee Breaks, Rock And Roll and Boogie With Stu [the latter would appear on Physical Graffiti]."
What was your approach to recording at that time?
"I'd been using very few mics on tracks like Can't Find My Way Home by Blind Faith. I had recorded the whole thing using just two mics including vocals, guitar and Ginger Baker's drums. So I was really getting into that."
John Bonham was famous for his very particular drum sound. How hands on was he?
"I never had Bonzo turn round to me and say, 'oh that's a great drum sound, Andy.' He'd just say, 'There's not enough 'frudge' on the bass drum.' That was his word and I knew exactly what he meant by 'frudge'."
"We took Bonham's kit and stuck it in this lobby area. I got a couple of microphones and put them up the first set of the stairs"
When The Levee Breaks put Bonham centre stage, held down by that monstrous 26" Ludwig bass drum. What was the process behind achieving that sound?
"One night Zeppelin were all going down the boozer and I said, 'You guys bugger off but Bonzo, you stay behind because I've got an idea.' So we took his kit out of the room where the other guys had been recording and stuck it in this lobby area. I got a couple of microphones and put them up the first set of the stairs."
I remember playing it back in the Stones' mobile truck and thinking, 'Bonzo's gotta f**king like this!
It wasn't just the stairwell that got that famous, earthy delay sound though...
"I used two Beyerdynamic M160 microphones and I put a couple of limiters over the two mics and used a Binson Echorec echo device that Jimmy Page had bought. They were Italian-made and instead of tape they used a very thin steel drum.
"Tape would wear out and you'd have to keep replacing it. But this wafer-thin drum worked on the same principle as a wire recorder. It was magnetised and had various heads on it and there were different settings. They were very cool things!
"And so playing at that particular tempo on 'Levee the limiters had time to breathe and that's how Bonzo got that 'Ga Gack' sound because of the Binson. He wasn't playing that. It was the Binson that made him sound like that.
"I remember playing it back in the Stones' mobile truck and thinking, 'Bonzo's gotta f**king like this!' I had never heard anything like it and the drum sound was quite spectacular."
What was Bonham's reaction to hearing the track back?
"I said: 'Bonzo, come and listen to this, dear chap.' And he came in and said, 'Oh yeah, that's more f**king like it!' And everyone was very happy. I guess I must have done it as a one-off thing and I didn't start using that technique of room mics all the time until later in the '70s with people like Rod Stewart.
"Jimmy picked up on it and used it on 'Kashmir'. When The Levee Breaks came out quite well and people still ask me about it when I appear on music biz panels and what-not."
You then moved onto Island Studios…
"Black Dog was the first thing we did there. That was a collaboration with Pagey and John Paul. My contribution to that was triple-tracking the guitar riff played on a Gibson Les Paul. I used a couple of universal limiters. It worked really well but as soon as Jimmy stopped playing, with all that gain it went 'Ssshh woarg!'"
Tell us about the recording of Rock And Roll and Stairway To Heaven…
"[Rock And Roll] was a little tough to record because with the hi-hat being so open and [Bonham] hitting it that hard it was difficult to control. But I managed somehow or another. We did Stairway To Heaven upstairs in the big room at Island.
"I had said to Jimmy that we needed a song that builds up and hadn't been having much luck. But then he said: 'I think I've got something that you'll like and we'll do it next week.' And he came in with Stairway To Heaven.
We got there just after a big earthquake had struck in 1971 and we were running around like maniacs
"We tracked it with drums and acoustic guitar and John Paul was playing an upright Hohner piano. I'd never even seen one before or since. The drums come in later because it's a 'building song', innit! I didn't have a lot to do with Stairway except for the 12-string guitar sound that I really liked at the time.
"Jimmy was always running his 12-string Rickenbacker through a box, which is a good sound. But if you do it direct and compress it, you get a much more bell-like quality. So I suggested we try that and he really liked it.
"There was a bit of a struggle on the solo. He was playing for half an hour and did seven or eight takes. He hadn't quite got it sussed. I was starting to get a bit paranoid and he said, 'No, no you're making ME paranoid.' Then right after that he played a really great solo."
The initial mixing sessions took place at Sunset Sound studios in LA...
"I had mixed an album with Gary Wright at Sunset and there were some wonderful mixes coming out of that studio. We got there just after a big earthquake had struck in 1971 and we were running around like maniacs. In Going To California there is mention of an earthquake in Robert's lyrics. I remember Jimmy saying: 'oh don't put that on there, it will cause another earthquake.' I said, 'oh, don't be so bloody stupid, gimme a break!'
As it turned out, mixing the album was an absolute disaster
"So the tapes began rolling and sure enough there was an aftershock. Totally coincidental of course but Jimmy was convinced it was the power of the music. So that was rather funny. But Peter Grant [Led Zep manager] would lie on his bed clutching the sides.
"He was a hard-nosed character but he was petrified of the earthquakes. Everyone thought the place was going to fall into the ocean. And as it turned out, mixing the album was an absolute disaster. That's why I didn't get to work with Zeppelin again after that album.
"It all sounded great at Sunset but the only mix that got used was When The Levee Breaks. That, for some reason turned out alright. But we did this playback at Olympic Studios in London and it wasn't the greatest place to hold a playback session. I should have chosen Island.
"Anyway the first song goes by and it doesn't sound very good at all. Jimmy and I are sitting on the floor with heads in our hands going 'What the hell is this?' Then we played the next one and the next one… and it all sounded 'orrible.
"The other three guys were turning round and giving us funny looks. 'What's happened here?' If it had been anyone else I would have been booted off the project there and then. Jimmy said: 'Well, that's not very good is it? Let's go back to Island where we should have been in the first place. We'll mix it there.'"
You must have been devastated?
"My bottle had gone and obviously I was shattered. The previous stuff I'd done at Sunset had come out Jim Dandy and was really good. I thought Sunset was a cool place but they had changed the room since I was last there. I don't know what happened. So we went back to Island and re-mixed Zeppelin IV although we still used the Levee Breaks mix from Sunset. But it had all cost a few bob, flying us over there to LA and staying at the Hyatt House. And I know that Bonzo was furious about it."
The When The Levee Breaks drum sound has been sampled and copied many times over the years, notably by the Beastie Boys.
"It's funny actually. I remember mixing some tracks in Tokyo and there were three 32-track machines all strapped together. It was insanity. One machine had all the percussion tracks and I found it even had a little of bit of When The Levee Breaks. Who would have thought all those years later I'd be stealing my own stuff!"
